Terragrunt: how to keep your Terraform code DRY and maintainable
In 2016, we released an open source tool called Terragrunt as a stopgap solution for two problems in Terraform: (1) the lack of locking…
In 2016, we released an open source tool called Terragrunt as a stopgap solution for two problems in Terraform: (1) the lack of locking for Terraform state and (2) the lack of a way to configure your Terraform state as code. Over the next few years, we were happy to see our solutions for both of these problems integrated into Terraform itself (in the form of Terraform backends), but new problems have since cropped up: namely, how to keep your Terraform code DRY and maintainable.
We just released Terragrunt v0.19.0, which has been updated to work with Terraform 0.12 and HCL2, and in this blog post, I’ll go over a few of the ways Terragrunt helps you in 2019:
- Keep your backend configuration DRY
- Keep your Terraform CLI arguments DRY
- Promote immutable, versioned Terraform modules across environments
Keep your backend configuration DRY
Terraform backends allow you to store Terraform state in a shared location that everyone on your team can access, such as an S3 bucket, and provide locking around your state files to protect against race conditions. To use a Terraform backend, you add a backend configuration to your Terraform code:
# stage/frontend-app/main.tf
terraform { backend "s3" { bucket = "my-terraform-state" key = "stage/frontend-app/terraform.tfstate" region = "us-east-1" encrypt = true dynamodb_table = "my-lock-table" } }
The code above tells Terraform to store the state for a frontend-app module in an S3 bucket called my-terraform-state under the path stage/frontend-app/terraform.tfstate, and to use a DynamoDB table called my-lock-table for locking. This is a great feature that every single Terraform team uses to collaborate, but it comes with one major gotcha: the backend configuration does not support variables or expressions of any sort. That is, the following will NOT work:
# stage/frontend-app/main.tf
terraform { backend "s3" { # Using variables does NOT work here! bucket = var.terraform_state_bucket key = var.terraform_state_key region = var.terraform_state_region encrypt = var.terraform_state_encrypt dynamodb_table = var.terraform_state_dynamodb_table } }
That means you have to copy/paste the same backend configuration into every one of your Terraform modules. Not only do you have to copy/paste, but you also have to very carefully not copy/paste the key value so that you don’t have two modules overwriting each other’s state files! E.g., The backend configuration for a database module would look nearly identical to the backend configuration of the frontend-app module, except for a different key value:
# stage/mysql/main.tf
terraform { backend "s3" { bucket = "my-terraform-state" key = "stage/mysql/terraform.tfstate" region = "us-east-1" encrypt = true dynamodb_table = "my-lock-table" } }
Terragrunt allows you to keep your backend configuration DRY (“Don’t Repeat Yourself”) by defining it once in a root location and inheriting that configuration in all child modules. Let’s say your Terraform code has the following folder layout:
stage ├── frontend-app │ └── main.tf └── mysql └── main.tf
To use Terragrunt, add a single terragrunt.hcl file to the root of your repo, in the stage folder, and one terragrunt.hcl file in each module folder:
stage ├── terragrunt.hcl ├── frontend-app │ ├── main.tf │ └── terragrunt.hcl └── mysql ├── main.tf └── terragrunt.hcl
Next, in each of your Terraform modules, remove the contents of the backend configuration:
# stage/mysql/main.tf
terraform { # Intentionally empty. Will be filled by Terragrunt. backend "s3" {} }
Now you can define your backend configuration just once in the root terragrunt.hcl file:
# stage/terragrunt.hcl
remote_state { backend = "s3" config = { bucket = "my-terraform-state" key = "${path_relative_to_include()}/terraform.tfstate"
region = "us-east-1" encrypt = true dynamodb_table = "my-lock-table" } }
The terragrunt.hcl files use the same configuration language as Terraform (HCL) and the configuration is more or less the same as the backend configuration you had in each module, except that the key value is now using the path_relative_to_include() built-in function, which will automatically set key to the relative path between the root terragrunt.hcl and the child module (so your Terraform state folder structure will match your Terraform code folder structure, which makes it easy to go from one to the other).
The final step is to update each of the child terragrunt.hcl files to tell them to include the configuration from the root terragrunt.hcl:
# stage/mysql/terragrunt.hcl
include { path = find_in_parent_folders() }
The find_in_parent_folders() helper will automatically search up the directory tree to find the root terragrunt.hcl and inherit the remote_state configuration from it.
Now, install Terragrunt, and run all the Terraform commands you’re used to, but with terragrunt as the command name rather than terraform (e.g., terragrunt apply instead of terraform apply). To deploy the database module, you would run:
$ cd stage/mysql $ terragrunt apply
Terragrunt will automatically find the mysql module’sterragrunt.hcl file, configure the backend using the settings from the root terragrunt.hcl file, and, thanks to the path_relative_to_include() function, will set the key to stage/mysql/terraform.tfstate. If you run terragrunt apply in stage/frontend-app, it’ll do the same, except it will set thekey to stage/frontend-app/terraform.tfstate.
You can now add as many child modules as you want, each with a terragrunt.hcl with the include { ... } block, and each of those modules will automatically inherit the proper backend configuration!
Keep your Terraform CLI arguments DRY
CLI flags are another common source of copy/paste in the Terraform world. For example, a typical pattern with Terraform is to define common account-level variables in an account.tfvars file:
# account.tfvars
account_id = "123456789012" account_bucket = "my-terraform-bucket"
And to define common region-level variables in a region.tfvars file:
# region.tfvars
aws_region = "us-east-2" foo = "bar"
You can tell Terraform to use these variables using the -var-file argument:
$ terraform apply \ -var-file=../../common.tfvars \ -var-file=../region.tfvars
Having to remember these -var-file arguments every time can be tedious and error prone. Terragrunt allows you to keep your CLI arguments DRY by defining those arguments as code in your terragrunt.hcl configuration:
# terragrunt.hcl
terraform { extra_arguments "common_vars" { commands = ["plan", "apply"] arguments = [ "-var-file=../../common.tfvars", "-var-file=../region.tfvars" ] } }
Now, when you run the plan or apply commands, Terragrunt will automatically add those arguments:
$ terragrunt apply
Running command: terraform with arguments [apply -var-file=../../common.tfvars -var-file=../region.tfvars]
You can even use the get_terraform_commands_that_need_vars() built-in function to automatically get the list of all commands that accept -var-file and -var arguments:
# terragrunt.hcl
terraform { extra_arguments "common_vars" { commands = get_terraform_commands_that_need_vars() arguments = [ "-var-file=../../common.tfvars", "-var-file=../region.tfvars" ] } }
Promote immutable, versioned Terraform modules across environments
One of the most important lessons we’ve learned from writing hundreds of thousands of lines of infrastructure code is that large modules should be considered harmful. That is, it is a Bad Idea to define all of your environments (dev, stage, prod, etc), or even a large amount of infrastructure (servers, databases, load balancers, DNS, etc), in a single Terraform module. Large modules are slow, insecure, hard to update, hard to code review, hard to test, and brittle (i.e., you have all your eggs in one basket).
Therefore, you typically want to break up your infrastructure across multiple modules:
├── prod │ ├── app │ │ ├── main.tf │ │ └── outputs.tf │ ├── mysql │ │ ├── main.tf │ │ └── outputs.tf │ └── vpc │ ├── main.tf │ └── outputs.tf ├── qa │ ├── app │ │ ├── main.tf │ │ └── outputs.tf │ ├── mysql │ │ ├── main.tf │ │ └── outputs.tf │ └── vpc │ ├── main.tf │ └── outputs.tf └── stage ├── app │ ├── main.tf │ └── outputs.tf ├── mysql │ ├── main.tf │ └── outputs.tf └── vpc ├── main.tf └── outputs.tf
The folder structure above shows how to separate the code for each environment (prod, qa, stage) and for each type of infrastructure (apps, databases, VPCs). However, the downside is that it isn’t DRY. The .tf files will contain a LOT of duplication. You can reduce it somewhat by defining all the infrastructure in reusable Terraform modules, but even the code to instantiate a module—including configuring the provider, backend, the module’s input variables, and output variables—means you still end up with dozens or hundreds of lines of copy/paste for every module in every environment:
# prod/app/main.tf
provider "aws" { region = "us-east-1"
# ... other provider settings ... }
terraform { backend "s3" {} }
module "app" { source = "../../../app"
instance_type = "m4.large" instance_count = 10
# ... other app settings ... }
# prod/app/outputs.tf
output "url" { value = module.app.url }
# ... and so on!
Terragrunt allows you to define your Terraform code once and to promote a versioned, immutable “artifact” of that exact same code from environment to environment. Here’s a quick overview of how.
First, create a Git repo called infrastructure-modules that has your Terraform code (.tf files). This is the exact same Terraform code you just saw above, except that any variables that will differ between environments should be exposed as input variables:
# infrastructure-modules/app/main.tf
provider "aws" { region = "us-east-1"
# ... other provider settings ... }
terraform { backend "s3" {} }
module "app" { source = "../../../app"
instance_type = var.instance_type instance_count = var.instance_count
# ... other app settings ... }
# infrastructure-modules/app/outputs.tf
output "url" { value = module.app.url }
# infrastructure-modules/app/variables.tf variable "instance_type" {} variable "instance_count" {}
Once this is in place, you can release a new version of this module by creating a Git tag:
$ git tag -a "v0.0.1" -m "First release of app module" $ git push --follow-tags
Now, in another Git repo called infrastructure-live, you create the same folder structure you had before for all of your environments, but instead of lots of copy/pasted .tf files for each module, you have just a single terragrunt.hcl file:
# infrastructure-live
├── prod │ ├── app │ │ └── terragrunt.hcl │ ├── mysql │ │ └── terragrunt.hcl │ └── vpc │ └── terragrunt.hcl ├── qa │ ├── app │ │ └── terragrunt.hcl │ ├── mysql │ │ └── terragrunt.hcl │ └── vpc │ └── terragrunt.hcl └── stage ├── app │ └── terragrunt.hcl ├── mysql │ └── terragrunt.hcl └── vpc └── terragrunt.hcl
The contents of each terragrunt.hcl file look something like this:
# infrastructure-live/prod/app/terragrunt.hcl
terraform { source = "github.com:foo/infrastructure-modules.git//app?ref=v0.0.1" }
inputs = { instance_count = 10 instance_type = "m4.large" }
The terragrunt.hcl file above sets the source parameter to point at the app module you just created in your infrastructure-modules repo, using the ref parameter to specify version v0.0.1 of that repo. It also configures the variables for this module for the prod environment in the inputs = {...} block.
The terragrunt.hcl file in the stage environment will look similar, but it will configure smaller/fewer instances in the inputs = {...} block to save money:
# infrastructure-live/stage/app/terragrunt.hcl
terraform { source = "github.com:foo/infrastructure-modules.git//app?ref=v0.0.1" }
inputs = { instance_count = 3 instance_type = "t2.micro" }
When you run terragrunt apply, Terragrunt will download your app module into a temporary folder, run terraform apply in that folder, passing the module the input variables you specified in the inputs = {...} block:
$ terragrunt apply
Downloading Terraform configurations from github.com:foo/infrastructure-modules.git...
Running command: terraform with arguments [apply]...
This way, each module in each environment is defined by a single terragrunt.hcl file that solely specifies the Terraform module to deploy and the input variables specific to that environment. This is about as DRY as you can get!
Moreover, you can specify a different version of the module to deploy in each environment! For example, after making some changes to the app module in the infrastructure-modules repo, you could create a v0.0.2 tag, and update just the qa environment to run this new version:
# infrastructure-live/qa/app/terragrunt.hcl
terraform { source = "github.com:foo/infrastructure-modules.git//app?ref=v0.0.2" }
inputs = { instance_count = 3 instance_type = "t2.micro" }
If it works well in the qa environment, you could promote the exact same code to the stage environment by updating its terragrunt.hcl file to run v0.0.2. And finally, if that code works well in stage, you could again promote the exact same code to prod by updating that terragrunt.hcl file to use v0.0.2 as well.
If at any point you hit a problem, it will only affect the one environment, and you can roll back by deploying a previous version number. That’s immutable infrastructure at work!
Try it out!
This has been a brief introduction to Terragrunt and a few of the reasons to use it in 2019. Check out the Terragrunt documentation for much more detail of what you can do.
We believe Terragrunt currently offers the best way to achieve DRY, maintainable, immutable Terraform code. We hope that, over time, all Terragrunt features will be rolled into Terraform, but in the meantime, give Terragrunt a shot as a stop gap solution, and let us know how it works out for you!
